DC 2000V ESS Fuse
- DC fuse designed for energy storage system (ESS) protection, GBS/BS/ESE series
- Rated voltage: DC 2000V | Rated current: 160A – 630A
- Rated breaking capacity: 250 kA | Protection category: aBat
- Provides protection against positive and negative fault current and short-circuit current
- UL, CE, TUV, CQC, and CCS certified
Interested?
- Send Inquiry Today!
Key Features:
- Part of the GBS/BS/ESE Series — engineered specifically for reliable overcurrent and short-circuit protection in energy storage and power systems
- Rated for DC 2000V with a current range of 160A to 630A, suited for smaller-scale and modular ESS configurations
- Exceptionally high breaking capacity of 250 kA for robust fault interruption in demanding environments
- aBat protection category — optimized for battery system protection on both positive and negative rails
- Low I²t value minimizes thermal stress on downstream components during fault conditions
- Low temperature rise and low power consumption contribute to improved overall system efficiency and reduced heat load
- Suitable for protection of both positive and negative fault current paths, including short-circuit events
- REACH declaration available upon request; RoHS compliant
Typical Applications:
- Photovoltaic (solar) and wind power energy storage stations
- Peak shaving and frequency regulation power stations
- Urban, microgrid, and island-grid energy storage systems
- EV charging station energy storage infrastructure
- Emergency backup power storage systems
- Household and commercial energy storage equipment
- Energy storage inverters, converters, and power supply protection
Certifications:
Product:
- UL
- CE
- TUV
- CQC
- CCS
- REACH declaration available upon request
- RoHS compliant
Electrical Specifications:
- Rated Voltage: DC 2000V
- Rated Current: 160A – 630A
- Rated Breaking Capacity: 250 kA
- Protection Category: aBat
- Series: GBS/BS/ESE
